| x-travel |
800 mm |
| y-travel |
800 mm |
| z-travel |
710 mm |
| control |
Uni-Pro CNC 90 |
| spindle diameter in front bearing |
100 mm |
| tool taper |
SK 50 |
| size of pallet |
630 x 500 mm |
| table indexing - automatic |
1° ° |
| workpiece diameter at full load |
112 mm |
| tool length - max. |
450 mm |
| turning speeds |
6000 U/min |
| workpiece diameter at full load |
112 mm |
| diameter of tools max. |
340 mm |
| tool length- max. |
450 mm |
| feed |
1 - 24 m/min |
| rapid traverse |
24 m/min |
| tool magazin: |
52 Places |
| weight of the machine ca. |
16,2 t |
| dimensions of the machine ca. |
6,00 x 4,10 x 4,10 m |
| Technical data without engagement |
|
